200 kVA Generator Rental in UAE | Silent Diesel Generator Hire Dubai
Rental Generator supplies factory load-bank tested 200 kVA silent diesel generators for demanding commercial and industrial sites across the UAE. Every unit is delivered with a current test certificate and full turnkey support from our 24/7 technical team.
Power Output: 200 kVA Prime (160 kW) and 220 kVA Standby (176 kW) at 0.8 PF.
Engine Platform: Cummins 6CTAA8.3-G2, a 6-cylinder, 8.3-litre turbocharged and charge-air-cooled block purpose-built for this duty class.
Acoustic Canopy: 71-75 dB(A) at 7m, with an enlarged radiator core and extended fan shroud rated for continuous 50°C ambient running.
Turnkey Support: 24/7 mobile engineer dispatch, trailer transport, and on-site commissioning across all seven Emirates.
200 kVA GENERATOR TECHNICAL SPECIFICATIONS
The 8.3-litre Cummins block gives this size class a higher torque reserve relative to its kVA rating than smaller 6.7L-engined sets, which is what underpins its motor-starting capacity. Below is the full build specification confirmed on your test certificate at delivery.
| Parameter | Specification |
|---|---|
| Prime Power Rating | 200 kVA / 160 kW @ 0.8 PF |
| Standby Power Rating | 220 kVA / 176 kW @ 0.8 PF |
| Continuous Operating Power (COP) | 182 kVA / 146 kW |
| Engine Series & Configuration | Cummins 6CTA8.3-G3 / Perkins 1306A-E87TAG4 / FG Wilson P176-3 — 6-Cylinder In-line, Turbocharged & Charge Air Cooled |
| Alternator Type | Stamford UCI274H or Leroy-Somer LSA 44.3, Brushless, Class H Insulation, IP23 |
| Voltage / Phase / Frequency | 400V / 230V, 3-Phase + Neutral, 50 Hz |
| Noise Level @ 7m | 71–75 dB(A), Soundproof Acoustic Canopy |
| Base Fuel Tank Capacity | 400–450 Litres, approx. 10–11 hours runtime at 75% Prime Load |
| Control Panel | Deep Sea DSE 7320 (standalone) or DSE 8610 (sync/paralleling), Auto-Start |
| Main Circuit Breaker | 3-Pole / 4-Pole Motorized MCCB, Adjustable Overload, Earth Leakage Protection |
| Dimensions (L x W x H) | 3,900 mm x 1,300 mm x 2,100 mm |
| Operating Weight | Dry: approx. 2,650 kg / Wet (full fluids): approx. 2,950 kg |
| Handling & Mobility | Single-point lifting eye, forklift pockets, lockable access doors |
ESTIMATED FUEL CONSUMPTION MATRIX
The 8.3-litre Cummins block carries a flatter specific fuel consumption curve under partial load than smaller-displacement engines, which keeps the 25-50% band more efficient than its rated capacity might suggest.
| Load Level | Output (kW) | Fuel Burn (L/hr) |
|---|---|---|
| 25% Load | 40 kW | 11.5 L/hr |
| 50% Load | 80 kW | 21.5 L/hr |
| 75% Load (Optimal Prime) | 120 kW | 31.0 L/hr |
| 100% Full Load | 160 kW | 41.0 L/hr |
Note: Based on diesel density of approx. 0.84–0.85 kg/L; a 3–5% tropical derating applies above 45°C ambient, and on-demand mobile fuel tanker delivery keeps extended runs topped up.
TYPICAL APPLICATIONS FOR 200 kVA GENERATORS IN UAE
This capacity is specifically sized for sites with one dominant high-draw motor plus standard balance-of-plant load, not for powering several large machines simultaneously.
Primary Construction & Industrial Equipment: A single 15-20 ton tower crane hoist motor at DOL start, concrete pump units, 2-3 submersible dewatering pumps running together, and full site office cabins.
Commercial Facility & Backup Scenarios: Mid-rise office floors (G+8 to G+15), standalone supermarkets, and clinic or diagnostic centre backup where imaging equipment needs clean, stable sine-wave power.
HVAC & Temporary Cooling Integration: Matched almost exactly to one 70-80 ton air-cooled package chiller, or four to five 10-15 ton split package AC units running concurrently.
Specialized Sector Application: Mid-size exhibition stands and VIP marquees at DWTC, and instrumentation or control room power during a single-train refinery shutdown package.
Grid Outage & Emergency Support: Sized for a localized DEWA/ADDC feeder trip affecting one building block, where a smaller unit would trip on inrush and a larger unit would run under-loaded all day.
WHAT IS INCLUDED IN OUR 200 kVA RENTAL PACKAGE?
Every rental is delivered as a complete turnkey package, not just the generator set. Here is the full scope of supply included or available on request.
Load-Bank Testing: 100% resistive load-tested certificate issued before dispatch.
Heavy-Duty Power Cables: Certified flexible rubber copper cables, 120 mm² to 150 mm² depending on run length.
Automatic Transfer Switch (ATS): Optional 250A–315A ATS panel for automated emergency failover.
Distribution Boards: Weatherproof MDB fitted with IP67 industrial CEE sockets (16A, 32A, 63A, 125A).
24/7 Technical Support: Dedicated mobile technician coverage and preventive servicing.
RAPID DELIVERY COVERAGE ACROSS THE UAE
Our fleet and technician teams are positioned to reach any Emirate quickly, with offloading and commissioning handled on-site. Delivery timelines below are standard across active rental contracts.
Dubai & Sharjah: Fast 2-hour emergency site delivery and connection.
Abu Dhabi, Mussafah & ICAD: Same-day delivery, electrical setup, and commissioning.
Northern Emirates (Ajman, RAK, UAQ, Fujairah): Scheduled turnkey deployment with mobile crane offloading.
Frequently Asked Questions
Rates depend on duration, location, and fuel inclusion, with longer contracts bringing a lower daily rate. Contact sales@rentalgenerator.ae or (+971) 56 921 3754 for a firm quote.
Yes, the 6CTAA8.3-G2's torque reserve supports a single DOL start up to approximately 45 kW before voltage dip exceeds 15%; larger motors should use a soft starter or VFD.
The cooling package is specified with extra margin for UAE ambient conditions, holding stable output with minimal nuisance tripping. A modest 3–5% derating may apply in peak summer, which we factor into sizing.
Yes, units fitted with DSE 8610 MKII panels synchronize automatically for combined capacity or N+1 redundancy, commonly used where a single 400 kVA set isn't available on short notice.
Rental Generator retains full responsibility for scheduled servicing and breakdown response throughout the contract. The client only handles day-to-day operation and prompt fault reporting.
